To scale up disinfection capabilities in high-flow water treatment circuits, securing a China Double H Type Submersible UV Sterilizer from professional Kingrate manufacturers represents the optimal commercial choice. This specialized equipment utilizes high-purity quartz glass to emit concentrated 254nm rays, breaking down pathogen DNA chains. Its fully submersible architecture ensures total contact with passing water, maximizing industrial operational uptime.
Industrial water lines often experience drops in disinfection performance when high water velocity reduces exposure time. The Double H Type Submersible UV Sterilizer design balances flow dynamics with high-output sterilization through multiple engineering optimizations:
• Folded Spatial Configuration: By mounting two parallel quartz tubes on a single compact base, this layout provides the disinfection power of a long linear lamp within half the physical length, saving equipment installation space.
• Optimized Current Density: The matched electronic ballast supplies independent electrical currents to each filament, preventing voltage drops and ensuring both tubes operate at full capacity with stable output.
• Minimizing Turbulent Flow Shadows: The physical spacing between the dual tubes creates a smooth, consistent water flow path, eliminating dark spots where bacteria could bypass UVC exposure and achieving full water body disinfection.
Model: Double H Type Submersible UV Sterilizer
Power: 40W, 60W, 100W and other different powers are optional
Lamp life: 8000-10000 hours
Material: Quartz glass
Size: Depends on the specific model
Certificate: CE, RoHS
Every Double H Type Submersible UV Sterilizer shipped to international commercial installations undergoes a strict automated testing protocol:
• High-Pressure Submersion Testing: Assembled lamp bases are submerged under water at twice the standard operating pressure for 24 hours to ensure the waterproof seals are completely secure.
• Spectral Energy Verification: Advanced sensors measure the 253.7nm output of every lamp, verifying that the light decay rate remains under 30% after long-term testing.
• Automated Failure Simulation: The control box is tested against sudden power surges and overheating scenarios to confirm that the automatic safety cutoff switches deploy instantly.
A: The Double H Type Submersible UV Sterilizer shortens overall equipment length while retaining equivalent power and UV output. It fits narrow water channels, compact filter sumps and small commercial water storage tanks where long straight lamps cannot be installed, greatly improving layout flexibility.
A: Static water around the tube will heat up gradually. Kingrate equips an automatic overheat shutdown function for protection. To extend quartz seal lifespan, link the lamp power supply to the water pump relay for synchronous start-stop.
A: Double H Type Submersible UV Sterilizer can light up normally, but suspended solids in turbid water will shield microbes from UV light and quickly contaminate the quartz surface. For ideal disinfection results, pre-treat water through sedimentation tanks, sand filters or micro screens to remove large particulate impurities first.
Each certification represents a commitment to our customers. KINGRATE UV lamps hold multiple patents and have obtained the following certifications, delivering tangible benefits to you:
1. CE Certification: Ensures product safety and reliability, reducing your procurement risks and legal disputes.
2. RoHS Certification: Guarantees the product is free of hazardous substances, protecting users and environmental health.
3. REACH Certification: Eliminates substances of very high concern from the product, simplifying your compliance management.
4. FCC Certification: Prevents electromagnetic interference, ensuring stable operation of your equipment systems.
5. ISO9001 Certification: Ensures consistent product quality, reducing after-sales issues and maintenance costs.
