For high-precision micro biological contamination control, sourcing from professional Kingrate PL-S Series H-Shaped UV Lamp PL-S5W manufacturers guarantees full technical compliance. With over 20 years of UV lamp R&D and production experience, we support customized OEM/ODM solutions, enabling seamless integration into modern household disinfection appliances without overall structural redesign.
• Ultra Space-Saving Geometry: Only 85mm in total length, perfectly adapted to ultra-narrow equipment cavities such as refrigerator water outlet modules and portable humidifiers.
• Green Energy Efficiency: Extremely low power consumption while maintaining over 99% inactivation rate against common bacteria and viruses, meeting global energy-saving and environmental protection standards.
|
Category |
Feature Name |
Description |
|
Product Features |
Efficient Sterilization |
Crafted from high - quality quartz glass with excellent light transmittance, this UV lamp can maximize UV output. It can effectively kill over 99% of common bacteria (such as Escherichia coli, Staphylococcus aureus) and viruses (such as influenza virus, novel coronavirus), providing reliable disinfection protection for different scenarios. |
|
|
Long Life |
With a service life of up to 9000 hours, compared with ordinary UV germicidal lamps (which generally have a service life of 3000 - 5000 hours), it can reduce the replacement frequency by more than half. This helps to save the cost of lamp replacement and the labor cost of maintenance, and also improves the continuous operation efficiency of related equipment. |
|
|
Energy Saving and Environmental Protection |
PL-S Series H-Shaped UV Lamp PL-S5W has low energy consumption, and its energy consumption is 30% - 50% lower than that of traditional sterilization equipment. During use, it has no toxic side effects, does not produce secondary pollution such as ozone, and its materials can be recycled. It meets environmental standards such as RoHS, making it an environmentally friendly sterilization choice. |
Flexible Installation: Its small size lets it slot into all kinds of small water treatment or air purification systems. Hardly any installation hassles.
Safe & Reliable: PL-S Series H-Shaped UV Lamp PL-S5W got CE, ROH, REACH, FCC certifications—meets European standards. Super reassuring, especially in medical or food industries where compliance is a big deal.
Easy Maintenance: The G23 single - ended lamp design? Swap out lamps in a snap. Low maintenance costs, and even regular folks can do the replacement easily.
|
Parameter |
Specification |
|
Model |
PL - S5W |
|
Power |
5W |
|
Lamp Head |
G23 |
|
Dimensions |
Maximum diameter: 12mm, Length: 85mm |
|
Lifespan |
Typically 9,000 hours; Some models offer up to 13,000 hours |
Kingrate optimizes internal filament alloy materials and adopts automatic tube clamping and sealing processes to avoid early cathode wear and failure. Compared with ordinary market lamps with only 5,000 hours of service life, the PL-S Series H-Shaped UV Lamp PL-S5W doubles the service life, greatly reducing customer replacement frequency and operating costs.
|
Category |
Application |
Description |
|
|
Applications |
Water Treatment |
Used for drinking water, wastewater treatment, and water disinfection in swimming pools, aquariums, and fish farms. |
|
|
Applications |
Air Purification |
Suitable for sterilizing and maintaining clean air in hospitals, laboratories, and air conditioning systems. |
|
|
Applications |
Industrial |
Suitable for surface disinfection of equipment and materials in industrial environments (e.g., food processing plants, pharmaceutical factories, breweries). |
|
|
Category |
Advantage |
Description |
|
|
Product Advantages |
Flexible Design |
Compact size makes it suitable for small water treatment and air purification equipment. |
|
|
Product Advantages |
Safety and Reliability |
Certified by CE, ROH, REACH, FCC, compliant with European standards to ensure safety. |
|
|
Product Advantages |
Easy Replacement |
G23 single - ended lamp design allows for easy replacement and low maintenance. |
|
A: Long-term direct UVC irradiation will age and crack ordinary plastic materials. The surrounding equipment shell must adopt UV-stabilized polymer materials or stainless steel shielding protection.
A: Low temperature reduces internal mercury vapor pressure and causes temporary flickering. The PL-S Series H-Shaped UV Lamp PL-S5W will stabilize automatically after 1–2 minutes of preheating, which is not a product defect.
A: Yes. When used for submerged water treatment, a matched quartz sleeve is mandatory to isolate electrical components from moisture and maintain optimal operating temperature.
Loose contact will cause increased contact resistance, resulting in local overheating of the lamp base, plastic deformation, unstable current and even automatic shutdown of the lamp.
No. 253.7nm UVC can kill more than 99% of surface bacteria in direct line-of-sight. Ozone is only auxiliary for blind-area sterilization. Pure UVC disinfection is cleaner and odor-free for small closed spaces.
Highly automated
We have introduced advanced fully automated lamp production equipment from abroad, making us one of the most highly automated manufacturers in the domestic industry. Key processes from filament winding and pinching to exhaust and aging are completed by automated equipment, significantly reducing human error.
Scaled production lines
Our modern Foshan factory is equipped with multiple complete production lines, enabling large-scale, standardized manufacturing of UV lamps. Whether order volumes are large or small, we deliver with consistent high-quality standards.
Ample capacity assurance
With continuous upgrades to automation equipment and production line optimization, our manufacturing capacity keeps growing. Even in the face of rising global order demand, we are fully capable of ensuring stable supply.
Efficiency and quality in one
Automated production not only increases output per unit time but also ensures consistency and reliability of every lamp through precise process control – a level of quality that is difficult to achieve with manual or semi-automated lines.
