To eliminate secondary contamination in precision consumer and medical appliances, Kingrate PL-S Series H-Shaped UV Lamp PL-S7W deliver certified stable performance. Adopting automated filament manufacturing and vacuum exhaust equipment, all products strictly comply with CE, RoHS, FCC and other global safety standards, supporting food contact and medical-grade disinfection scenarios.
|
Category |
Description |
|
Model |
PL - S7W |
|
Power |
7W (Energy - efficient and eco - friendly, suitable for long - term use) |
|
Lamp Head |
G23 (Easy to install and replace) |
|
Dimensions |
Maximum diameter 12mm, length 115mm. The compact size enables easy installation in small devices or confined spaces. |
|
Lifespan |
Typically 9,000 hours; Some models can last up to 13,000 hours, reducing lamp replacement frequency and saving long - term costs. |
The PL-S Series H-Shaped UV Lamp PL-S7W, with its high sterilization rate and compliance certification, fully meets GMP standards. Breweries use it for surface disinfection of fermentation tanks and filling equipment, preventing contamination of beer by bacteria and ensuring a consistently high taste and quality. Let's discuss its product advantages: its flexible design makes it easy to integrate into compact devices like small water purifiers and desktop air purifiers, eliminating the need for manufacturers to significantly redesign the device to accommodate the lamp. Its safety features are also reassuring, with CE, ROH, REACH, and FCC certifications, ensuring compliance with European standards.
• Under-Sink Water Dispensers: PL-S Series H-Shaped UV Lamp PL-S7W serves as the final disinfection procedure of RO reverse osmosis water systems to ensure tap water is free of pathogenic microorganisms.
• Laminar Flow Hoods & Cleanrooms: Installed in medical laboratory equipment to sterilize working surfaces and test tools, effectively preventing experimental sample cross-contamination.
• Small Aquariums and Fish Farms: Controls green water and algae reproduction in small water bodies, reduces aquaculture disease treatment costs and improves fish survival and yield.
|
Category |
Description |
|
UV Sterilization |
Emits 253.7nm C - band UV light, effectively destroys microbial DNA, with a sterilization rate of over 99% for common bacteria and viruses. |
|
Ozone - Free Design |
Eliminates side effects caused by ozone, suitable for environments with high air quality requirements (e.g., hospitals, laboratories). |
|
Energy - Saving & Long - Lasting |
High UV emission efficiency, low energy consumption, and long lifespan, making it an economical and eco - friendly disinfection solution. |
Flexible Design: Compact size makes it suitable for small water treatment and air purification equipment.
Safety and Reliability: CE,ROH, REACH, FCC certified, compliant with European standards, ensuring safety.
Easy Replacement: The G23 single-ended lamp design allows for easy replacement and low maintenance.
The PL-S Series H-Shaped UV Lamp PL-S7W, with its high efficiency, safety, and cost-effectiveness, is widely used for disinfection and sterilization in various fields, making it an ideal choice for ensuring hygiene and safety.
A: No. Although the G23 base is physically compatible, the operating current parameters are different. Mismatched ballast driving will cause overcurrent and instant filament burnout.
A: Adopts high-purity dehydroxyl quartz glass, which resists thermal stress and structural deformation, maintaining stable UVC transmittance during long-term high-temperature operation.
A: PL-S Series H-Shaped UV Lamp PL-S7WUse a professional 254nm UVC radiometer or test card for detection. The visible blue light is only a byproduct of mercury discharge and cannot represent actual sterilization intensity.
Yes. Continuous 24/7 operation is more conducive to prolonging the service life. Frequent startup and shutdown will cause severe fatigue damage to the filament, while continuous stable operation can maximize the 13,000-hour service life.
KINGRATE combines large-scale manufacturing with flexible customization to deliver an efficient and agile service experience:
1. Automated production lines with ample capacity
Our modern Foshan factory is equipped with filament winding, pinching, exhaust, aging, and other automated lines, with continuously expanding capacity to handle bulk orders.
2. Short lead times guaranteed
Through scaled production and optimized scheduling, we ensure on-time delivery even as order volumes grow, helping you seize market opportunities quickly.
3. Dedicated OEM/ODM service
We have a specialized workflow with assigned personnel at every stage, from specification confirmation and sample validation to mass delivery, ensuring that non-standard requirements are precisely met.
4. Consistent quality
While accommodating customization, we maintain standardised operations and strict quality control to ensure batch-to-batch reliability without compromising on performance.
5. Full-process customer care
We provide professional selection guidance before sales, regular progress updates during production, and immediate resolution of quality issues after sales, so you are supported at every step.
6. Flexibility for urgent needs
For tight deadlines or last-minute order changes, our production scheduling system can adapt quickly to minimise any impact on your projects.
